Features
Transmission of ordinary fluids, longer hose life; transmission of viscous liquids or transmission is sensitive to shear
The fluid effect is better.
Large torque, maintenance-free AC geared motor drive, frequency converter speed regulation.
High protection grade IP55.
The explosion-proof grade of the motor is DIIBT4.
The inverter is not explosion-proof and should be placed in a safe area when using it
Transmission of ordinary fluids, longer hose life; transmission of viscous liquids or transmission is sensitive to shear
The fluid effect is better.
Large torque, maintenance-free AC geared motor drive, frequency converter speed regulation.
High protection grade IP55.
The explosion-proof grade of the motor is DIIBT4.
The inverter is not explosion-proof and should be placed in a safe area when using it
| Applicable range of speed | 60-600RPM | working environment | Temperature 0-40℃, humidity <80%, no condensation |
| Flow range | 4-12000mL/min | Dimensions (length x width x height) | 572×250×281mm（不帶泵頭） |
| Theoretical resolution of speed adjustment | 0.6RPM | Drive weight | 27kg (without inverter) |
| Display method | Digital Tube | Protection level | IP55 |
| Applicable power supply | AC three-phase 380V | Motor explosion-proof grade | DIIBT4 |
| Maximum power | <400W | Motor fan power supply | AC three-phase 380V |
| Inverter parameters (motor driver) | |
| project | data |
| Inverter model | RF300-R75G-1 |
| Inverter power supply | AC three-phase 380V |
| Three-phase power terminal description | The R, S, and T terminals correspond to the three-phase U, V, and W. |
| Pump head model | hose | Flow range (mL/min) |
| YZ1515 | 13#14#19#16#25#17#18# | 4-2280 |
| YZ2515 | 15#24# | 96-1600 |
| KZ25 | 15#24#35#36# | 180-6000 |
| YZ35 | 73# | 600-6000 |
| 82# | 1200-12000 |
